WATER QUALITY ANALYZER

WATER QUALITY ANALYZER High-precision TurbidimeterAqua2000-TU90/
UCX
  • NEP
  • 조달청
  • 굿디자인
Catalogue Download Product List

The high-precision turbidimeter TU90/UCX is a device that measures turbidity and water temperature automatically and continuously in the measurement range 0 ~ 2/10 / 200NTU. With automatic flushing function, it can measure accurately at low concentration as well as at high concentration, and the turbidity is accurately measured by removing the micro bubbles in the sample water with the bubble removal patented technology. It is designed to be suitable for the domestic water environment by dramatically reducing the waste of water by using the natural sample flow type and it’s compact size.

Product Specification

Product Specification
Instruction Calculation Part
  • Display4.3 Inch Touch TFT LCD Touch Panel
  • Size153(W) x 150(H) x 140(D) mm
  • WaterproofIP65
  • Power/Power ConsumptionAC100/240V, 50/60Hz, 10W
  • Output4~20mA, 2CH
  • CommunicationRS232, RS485 (option)
  • DownloadUSB, SD card (option)
Turbidity
  • Measurement method90° scattering light method
  • Light sourceTungsten Lamp
  • StructureEquipped with multi-bubble removal flow paths
  • Measurement range0~2/10/200NTU (avaliable to set the range)
Water Temperature
  • Measurement methodPT1000Ω
  • Electrode materialPlatinum thermometer (built in water quality sensor)
  • Measurement range-20 ~ 70℃

Installation Case

  • Block drain network jang seong gun 2023.11.02
  • purification plant wonju si 2023.01.19
  • wonju si 2022.12.20
  • Reservoir Jang su-gun 2023.02.20
