WATER QUALITY ANALYZER

WATER QUALITY ANALYZER Free Chlorine AnalyzerAqua2000-FCL/
AP38D
  • 조달청

Non-Reagent Residual Chlorine Aqua2000-FCL is a device that measures and transfers data of residual chlorine and pH in real time automatically and continuously. The advantage of this product is easy to check the sensor status, easy maintenance and user-friendly interface. And pH and temperature compensation allow accurate measurement of residual chlorine in various environments.

Product Specification

Product Specification
Instruction Calculation Part
  • Display4.3 Inch Touch TFT LCD Touch Panel
  • Size195(W) x 183(H) x 90(D) mm
  • WaterproofIP65
  • Power/Power ConsumtionAC100/240V, 50/60Hz, 10W
  • Output4~20mA, 2CH
  • CommunicationRS232, RS485 (option)
  • DownloadUSB, SD card (option)
Free Chlorine
  • Measurement MethodPolarograph Amperometric
  • ElectrodGold Cathode, Silver Anode(Anodizing)
  • StructurepH and temperature auto compensation
  • Measurement range0~2/10/20mg/L (avaliable to set the range)
Water Temperature
  • Measurement rangePT1000Ω
  • Electrode materialPlatinum thermometer (built in water quality sensor)
  • Measurement range-20 ~ 70℃

Installation Case

  • purification plant jangsu gun 2023.11.02
  • chemical facility chang yeong gun 2022.09.07
  • Drinking water facility Cafeteria in golf course 2023.02.20
  • Drinking water facility Cafeteria in training center 2023.02.20
  • Drinking water facility Cafeteria in funeral hall 2023.02.20
  • Drinking water facility Restaurant in Rest Area 2023.02.20
  • Drinking water facility Cafeteria in factory 2023.02.20
